MCP uses a host-client-server architecture. The host runs the AI experience, each MCP client manages one server connection, and MCP servers provide focused capabilities such as tools, resources, and prompts.
This structure keeps orchestration in the host and separates external integrations into independently managed servers. MCP architecture diagram showing one host, multiple isolated clients, and multiple local or remote servers

​
The four architectural layers

You can understand an MCP system as four layers: The external system may be an API, database, SaaS platform, file system, or internal service. It is not itself required to implement MCP when an MCP server wraps it.

​
MCP host

The host is the application the user interacts with. It may be an AI assistant, coding environment, desktop application, or internal agent platform. The host typically:
  • Creates and manages MCP clients
  • Controls which servers can connect
  • Coordinates model interactions
  • Presents permission and approval interfaces
  • Combines context from approved sources
  • Enforces application-level security policies
The host owns the conversation. An MCP server should receive only the information needed for its operation.

​
MCP client

An MCP client is the protocol component inside the host. Each client normally maintains a one-to-one connection with a server. It:
  • Initializes the session
  • Negotiates supported capabilities
  • Routes requests, responses, and notifications
  • Tracks the server connection
  • Preserves isolation from other server connections
One host can run several clients at the same time. This allows an AI application to use multiple servers without giving those servers direct access to one another.

​
MCP server

An MCP server provides context or actions to clients. A server may run as a local process or as a remote service. It can expose: Servers should have focused responsibilities. A server that wraps a billing API, for example, should expose only the billing capabilities its users need.

​
Server and client features

MCP supports features on both sides of the connection. Common server features include tools, resources, and prompts. Client features can include roots, sampling, and elicitation. These are not assumed. The client and server declare supported capabilities during initialization.

​
Capability negotiation

Capability negotiation lets both sides agree on available protocol features. During initialization:
  1. The client declares the features it supports.
  2. The server declares the features it supports.
  3. Both sides use only the capabilities available for that session.
This design allows implementations to add features progressively. A simple tool server does not need to implement every part of MCP.

​
Message layer

MCP messages use JSON-RPC 2.0 structures:
  • Requests expect a response.
  • Responses contain a result or error.
  • Notifications do not expect a response.
The message layer is separate from the transport. The same protocol behavior can run over stdio for local processes or Streamable HTTP for remote services. Read The MCP specification for the normative protocol requirements.

​
Transport layer

The transport moves messages between the client and server. The standard transports are:
  • stdio
  • Streamable HTTP
stdio commonly connects a host to a child process on the same machine. Streamable HTTP supports network-accessible servers and normal HTTP infrastructure. Transport choice affects deployment, authentication, latency, and operational responsibility. Compare these tradeoffs in Local vs remote MCP.

​
Security boundaries

The host-client-server design creates important boundaries:
  • Servers should not automatically receive the full conversation.
  • One server should not see another server’s data.
  • The host should control user consent.
  • Tool descriptions and results should be treated as untrusted input.
  • Sensitive actions should require clear authorization.
  • Servers should apply least-privilege access to underlying systems.
MCP defines communication behavior, but implementation security remains the responsibility of the host and server developers.

​
Example architecture for an API-backed server

An API-backed MCP deployment may look like this:
The MCP server translates an MCP capability request into an API request. The API remains the authority for business logic and data access. 0mcp uses this pattern to turn an OpenAPI specification into a hosted MCP interface.

​
Architecture vs request lifecycle

Architecture describes the components and their boundaries. The lifecycle describes the order of messages inside one connection. For the message sequence from initialization to results, read How MCP works, step by step.

​
Key takeaway

MCP architecture separates the AI host, protocol connections, and external capabilities so each part can remain focused, composable, and governed.
